DESCRIPTION:

Artnet Controller

1. Artnet Controller include 3 parts, 1st is standard 8/16 node,

2nd is 1/4/12/20/30 lightning series, 3rd is easy artnet

2. The Artnet DMX controller Completely follow standard USITT

DMX512/1990 protocol and the expanded DMX512 protocol,

3. The Artnet DMX controlller also compatible with WS2801,

WS2811, SM16716, TM1804, UCS1903 etc with external DMX decoder

4. Compatible with Art-net protocol and many LED editing softwares

5. RJ45 in & out, with built in switch, realize series connection between

different Artnet DMX controller

6. Protections: short circuit, over current , over temperature .

Application: adapted for all kinds of led lighting control with dmx 512 protocol way.


  • Parameters
  • Dimension
  • Diagram
  • Datasheet

1st type Standard DMX Art-Net Node, 8/16 Art-Net Node

Model

LED-ANC8x512

LED-ANC16x512

Universe

8

16

Working Voltage

AC 110 -240V

Output Protocol

DMX512

Output connector

3/5 pin XLR female

Support software

Madrix, SUNLITE, Arkaos, Martin, Avolite

Input Protocol

ART-NET II, ART-NET III

Ethernet/Art-Net

RJ45, 10/100Mbit/s

Working temperature

-20℃-+50℃

Working Environment

IP20,Indoor use only

Dimension

483x155x44 mm

483x155x88 mm

Net Weight

0.9KG

1.86KG


2nd is 1/4/12/20/30 lightning series

Model

Lightning 1

Lightning 4

Lightning 12

Lightning 20

Lightning 30

CPU

ARM

ARM+FPGA

Input Protocols

ART-NET II, ART-NET III

ART-NET II, ART-NET III, sANC

Configuration

IP address, Artnet Name

Output Protocols

DMX512

Input Connection

RJ45

Output Connector

3pin/5pin XLR female

Input Voltage

DC5-24V

AC90-250V

Input Power (Max)

2W

5W

Dimension

70x63x38 mm

125x70x45 mm

483x155x44 mm

482.6x130x88mm

482.6x130x88mm

Net Weight

0.3kg

0.7kg

1.0kg

2.0kg

2.0kg


3rd is easy artnet way

Model

LED-S4

LED-S8

Input Protocols

ART-NET II, ART-NET III

ART-NET II, ART-NET III

Output Protocols

DMX, SPI

DMX, SPI

Input Connection

RJ45

RJ45

Output Connection

SM port/4Pin/3XLR/5XLR/TBD

Open wire

Input Voltage

AC 110V / AC 220V

AC 110V / AC 220V

Power Consumption

1.2W

1.2W

Control pixels

4x512ch for dmx,

3400pixels in total for SPI

8x512ch for dmx,

6800pixels in total for SPI

Net Weight

1Kg

1Kg

Protection

IP40/ Rainproof

IP40

Dimension

L163 x W155 x H54mm

L183 x W139 x H40mm





Artnet Controller Dimension Details



Please contact our sales for the lastest version of user manual, thanks
