DESCRIPTION:

DMX Magic ball

1. Diameter 15cm, 20cm, 30cm, 40cm and 50cm available

2. DC 24V input

3. One ball one M4 short clevis

4. Milky cover giving 360° viewing,

5. Standard DMX 512 control, 44frames/second, manual addressing

6. Protections: short circuit, over current , over temperature

Application: Mostly for stage lighting, shop decoration, park decoration, celebration and so on.




  • Parameters
  • Dimension
  • Diagram
  • Datasheet

Model NO.

LED-MB150DMX1201

LED-MB200DMX1801

LED-MB300DMX2401

LED-MB400DMX2401

Diameter

150mm

200mm

300mm

400mm

Housing

Milky white

Color

SMD RGB 5050

View Angle

360degree

LED QTY

12LEDs

18LEDs

24LEDs

24LEDs

Pixel QTY

1 Pixel

1 Pixel

1 Pixel

1 Pixel

DMX Channels

3Channels

3Channels

3Channels

3Channels

Tube Qty/Universe

170balls/universe

170balls/universe

170balls/universe

170balls/universe

Control Protocol

Standard DMX512

Operating Voltage

DC24V

DC24V

DC24V

DC24V

Max Power

MAX=2.88W

MAX=4.32W

MAX=5.76W

MAX=5.76W

LED Source Life

50,000hours,based on LED manufacturers’ test data

Temperature

-20℃ to 50℃ operating temperature

Humidity Range

0 to 95% non-condensing

Protection

IP43  standard (wateproof IP65 can do as well please declare for the application)






DMX Magic ball Datasheet
